Molybdenum Plate
Material from .090 inches to 3 inches in thickness is classified as Molybdenumplate. It is widely used in the construction of furnace tooling and parts and as a feed stock for the fabrication of parts for the electronics and semiconductor industries. Standard availability is described below. Other sizes and tolerances are available.

Thickness	Max. Width	Max. Length
.090"	24"	110"
.125"	24"	80"
.250"	24"	40"
.500"	24"	24"
>.500"	24"



For greater thickness, plate products are normally limited to 40 kilograms maximum weight per piece.

Molybdenum Plate Standard Thickness Tolerance


Thickness	.25" to 6"	6" to 12"	12" to 24"
.090"	± .005"	± .005"	± .005"
> .125	± 4%	± 4%	± 4%



Molybdenum Plate Standard Width Tolerance





Thickness	.25" to 6"	6" to 12"	12" to 24"
.090"	± .031"	± .031"	± .031"
> .125	± .062"	± .062"	± .062"



Surface Condition
Surface can be supplied in a shiny, matte, or as-rolled condition; dependent upon thickness and width parameters.

Heat Treatment
Molybdenum flat products are rolled and annealed to provide the optimum condition for the desired end use.
Molybdenum Sheet
Material from .005 inches to .090 inches in thickness is classified as molybdenum sheet. It is used for fabrication of sintering boats, high temperature furnace heating elements and heat shields. Standard availability is described below. Other sizes and tolerances are available.



Thickness	Max. Width
.005" to .015"	24"
> .015" to .040"	24"
> .040" to .090"	24"
Length is dependant on surface condition required and width.





Molybdenum Sheet Standard Thickness Tolerance





Thickness	.25" to 6"	6" to 12"	12" to 24"
.005" - .009"	± .0005"	± .0005"	± .002"
.009" - .015"	± .0008"	± .0009"	± 10%
.015" - .020"	± .0010"	± .0010"	± 10%
020" - .040"	± .0015"	± .0015"	± 10%
.040" - .050"	± .003"	± .003"	± 10%
.050" - .065"	± .004"	± .004"	± .004"
.065" - .090"	± .005"	± .005"	± .005"



Molybdenum Sheet Standard Width Tolerance



Thickness	.25" to 6"	6" to 12"	12" to 24"
.005" - .009"	± .012"	± .015"	± .025"
.009" - .015"	± .012"	± .015"	± .025"
.015" - .020"	± .012"	± .020"	± .025"
020" - .040"	± .020"	± .030"	± .030"
.040" - .050"	± .020"	± .030"	± .030"
.050" - .065"	± .020"	± .030"	± .030"
.065" - .090"	± .030"	± .005"	± .031"

Surface Condition
Surface can be supplied in a shiny, matte, satin, or as-rolled condition; dependent upon thickness and width parameters.

Heat Treatment
Molybdenum flat products are rolled and annealed to provide the optimum condition for the desired end use (Furnace, Punch, Deep Draw).



Special sizes are available, please contact sales for inquiries.
